IoT wireless thermometer, hygrometer, barometer, LoRaWAN network

The W7910 sensor with LoRaWAN network output measures the temperature, humidity and atmospheric pressure from the built-in internal sensors and can be installed directly in the measured environment thanks to its IP65-rated enclosure. LoRa devices are powered by a replaceable battery with a lifespan of up to 10 years (3 years standard).

Measured values are transmitted wirelessly at adjustable intervals (from 5 minutes to 24 hours) to the COMET Cloud storage, where they are accessible to users via computer or mobile device. The sensors offer remote configuration from the COMET Cloud and feature the capability to monitor up to two alarm thresholds, with any exceedance signaled by an alert sent to the user.

Key Features

Wireless transmission of measured values and alarm states
Battery-powered with low battery indicator (battery life up to 10 years)
Remote device configuration via COMET Cloud
IP65-rated enclosure
Calibration certificate with declared metrological traceability of standards according to CSN EN ISO/IEC 17025
Preconfigured Gateway available as an accessory at extra cost. For ease of use, we offer the pre-configured LoRaWAN Gateway, which is fully ready for communication with COMET Cloud and our sensors. This option simplifies the setup process and saves time for users

Termékkód

W7910
Garancia

3 év

Send request

Műszaki adatok

Mért paraméter

Hőmérséklet

Relatív páratartalom

Számított érték (harmatpont…)

Légköri nyomás

TEMPERATURE SENSOR

Measuring range -30 to +60 °C

Accuracy ±0.4 °C

Resolution 0.1 °C

Response time t90 of temperature measurement (temperature step 20°C, air flow approximately 1m/s) 10 minutes

HUMIDITY SENSOR

Measuring range 0 to 100 % RH

Accuracy ±1.8 % RH from 0 to 90 % at 23 °C

Resolution 0.1% RH

DEW POINT

Measuring range -60 to +60 °C

Accuracy ±1.5 °C at ambient temperature T <25 °C and RH >30 %

Resolution 0.1 °C

ATMOSPHERIC PRESSURE SENSOR SENSOR

Measuring range 600 to 1100 hPa

Accuracy ±1.3 hPa at 23 °C from 800 to 1100 hPa

Resolution 0.1 hPa

GENERAL TECHNICAL DATA

Operating temperature -30 to +60 °C

Channels internal sensor of temperature, humidity sensor and atmospheric pressure

Message transmission interval adjustable 5-10-15-20-30 minutes, 1-2-3-4-6-8-12-24 hours

Operating frequency Europe 863-870 MHz

Maximum transmission power 25 mW (14 dBm)

Typical range of transmitter 15 km in the field, 2 km in the city (sensor in building)

Antenna internal, gain 2,15 dBi

Maximum receiver sensitivity -136 dBm @BW=125 kHz, SF=12

Power Lithium battery 3.6 V, AA size

Protection class IP65

Dimensions 126 x 89 x 40mm

Weight (including batteries) 150g

Warranty 3 years

Countries using the LoRaWAN EU 868 frequency plan

Europe:

Aland Islands, Albania, Andorra, Austria, Belarus, Belgium, Bosnia and Herzegovina, Bulgaria, Croatia, Czechia, Cyprus, Denmark, Estonia, Faroe Islands, Finland, France, Georgia, Germany, Gibraltar, Greece, Holy See, Hungary, Iceland, Ireland, Isle of Man, Italy, Jersey, Latvia, Liechtenstein, Lithuania, Luxembourg, Macedonia, Malta, Moldova, Monaco, Montenegro, Netherlands, Norway, Poland, Portugal, Romania, San Marino, Serbia, Slovakia, Slovenia, Spain, Svalbard and Jan Mayen, Sweden, Switzerland, Ukraine, United Kingdom

Africa:

Benin, Botswana, Burundi, Cabo Verde, Comoros, Côte d’Ivoire, Egypt, Equatorial Guinea, Kenya, Madagascar, Mauritania, Mayotte, Namibia, Nigeria, Reunion, Rwanda, Senegal, Somalia, South Africa, Tunisia, Zambia

Asia:

Armenia, Bahrain, Bhutan, Brunei Darussalam, Cambodia, Iran, Kuwait, Lao People’s Democratic Republic, Lebanon, Oman, Philippines, Qatar, Saudi Arabia, Syria, Turkey, United Arab Emirates

North America:

Greenland, Saint Pierre and Miquelon

South America:

Bonaire, Sint Eustatius and Saba, Falkland Islands, French Guiana, Guadeloupe, Martinique, Saint Barthelemy, Saint Martin

Oceania and Others:

French Polynesia, New Caledonia, Samoa, Wallis and Futuna, Bouvet Island, French Southern Territories, South Georgia and the South Sandwich Islands
